Yes if your lcd panel is dim or black but showing faint data we would be pleased to repair the Brightness problem for you.

We prefer if you can take out the LCD and mail only the panel for a professional refit and repair and test, purchases of backlights are for professionals who now how to fit correctly, if fit by a novice the lcd panel may show lines or blocks of bad data, or hissing noise from badly soldered joints at the lamp connections. Warning high voltage is applied to the CCFL to create light inside the lcd housing.

Yes we can mail only the CCFL to you if you are a qualified LCD technician.
To purchase your replacement LCD backlight lamp Click below for Total costs inclusive of air mailing

You will save $12 on all CCFL orders that are sent as checks mailed to this link payment >> address or paid to GoogleCheckout at $26 per All New lamps guaranteed in stock

We also sell new backlights for 15.4" Widescreen LCD CCFL use link below and new backlight for 17" LCD CCFL at 374mm fits Screens like the HP ZD7000
For all other CCFL sizes required, please use this payment link

Please be aware if you used the payment link with unspecified LCD size we need the lamp length or the LCD size, after payment in order that we can mail you the correct replacement CCFL. reference # will show as a 2checkout.com # :: Please be sure to quote the Order Number: [Example 32201415 CCFL order] as subject in Email after order is placed and your payment

Is there a difference between the CCFL lamp and a backlight assembly?

My assumption is that an assembly is more plug and play while a lamp requires more disassembly soldering and new silicon end caps / then assembly. I found one assembly for the Inspiron 4100 on the web but it's out of stock. Do you carry the full assembly?

Well yes we only mail out new lamps although for free if you wish I can accept the complete LCD reflector assembly from any customer and solder and fit a new backlight for you tested and mail it back to you at the same cost of just the new Backlight lamp.

reference # and international or USA destination address. or Call 435 634 0681
CCFL,s can run at lower operating voltages, and can be 300 volts higher or 300 volts lower than specified.

COLD CATHODE FLUORESCENT LAMPS (CCFL)				CCFL's typically run at around 117Khz

Our code	Diameter (mm)	Length (mm)	Lamp voltage	Lamp Watts	Starting	Intensity
Our code	Diameter (mm)	Length (mm)	VL Vrms	At 5mARMS	Voltage Typ. Vrms	Cd./m2
10.4" LCD 12.1" LCD 13.3" LCD 14.1" LCD 14.4" LCD Wide 15.1" LCD 15.4" LCD Wide 16.1" LCD 17.0" LCD	2.2 2 2 2 2 2 2 2.1 2.1	210 260 273 292 312 307 338 337 374	850 900 1150 1200 1200 1200 1400 1400 1500	3.5 3.7 4.1 4.7 4.7 4.8 4.9 5 5.6	1700 1820 1830 1870 1870 1880 1880 1899 1900	36.500 37.000 37.500 38.500 38.500 38.000 38.080 39.000 39.900

***** Mailing Time ----------------- All prices above include mailing 1st class air anywhere in the world. *****

IF you need help as to how to take your notebook LCD housing apart
see this link -> www.lcdrepair.net/lcdhousing.htm
Or if Sony VAIO like the 16.1" see this link -> www.lcdrepair.net/grx500p/GRX500P.html

Yes we can supply lamps in large quantities of 80 lamps or more.
please call 435 634 0681 and leave a message or use the EMAIL US

3044 Bayberry Cir Saint George Utah 84790 USA
